CW 50 Casement Series
CW 50 Casement Series
Premium Heavy-Duty Aluminium Casement Window System
The CW 50 Casement Series is a premium aluminium casement window system designed for superior strength, enhanced thermal performance, and contemporary architectural aesthetics. Manufactured using high-quality 6063-grade aluminium alloy, this system delivers outstanding durability, smooth operation, and long-lasting performance for residential, commercial, and institutional applications.
Supporting glass thickness up to 40 mm, the CW 50 Casement Series provides excellent insulation, improved security, and elegant styling, making it an ideal solution for modern buildings that demand both performance and design.
Designed for Modern Architecture
The CW 50 Casement Series combines robust aluminium profiles with precision engineering to create windows that offer excellent ventilation, natural light, and weather resistance. Its sleek profile design complements contemporary architecture while providing reliable functionality and low maintenance.
Whether used in luxury homes, office buildings, hotels, or commercial developments, the CW 50 Casement Series ensures exceptional quality and lasting value.
Key Features
Product Features
Premium Aluminium Construction
Manufactured using 6063-grade aluminium alloy to provide excellent strength, corrosion resistance, and long-term durability.
Superior Glass Compatibility
Supports glass up to 40 mm, allowing the use of double-glazed, laminated, insulated, and toughened glass for enhanced thermal and sound insulation.
Maximum Ventilation
The casement opening design allows maximum airflow while providing unobstructed outdoor views and abundant natural light.
Enhanced Security
Compatible with both single-point and multi-point locking systems, offering greater safety and dependable protection.
Precision Engineering
Accurately manufactured frame and sash profiles ensure smooth operation, secure sealing, and exceptional weather resistance.
Contemporary Design
Slim aluminium frames provide a clean, modern appearance suitable for luxury residential and commercial architecture.
Technical Specifications
|
Specification |
Details |
|
Profile Alloy |
6063 Aluminium |
|
Maximum Window Size |
2000 mm Width / 3600 mm Height |
|
Frame Size |
50 mm / 45 mm |
|
Frame Corner |
45° |
|
Sash Corner |
45° |
|
Sash Size |
58.50 mm / 79 mm (W) – 58.50 mm / 92.40 mm (D) |
|
Glass Thickness |
Up to 40 mm |
|
Locking System |
Single / Multi-Point |
|
Mosquito Mesh Solution |
No |
Ideal Applications
The CW 50 Casement Series is ideal for:
