Sliding Folding 3.0 IMP Series
Sliding Folding 3.0 IMP Series
Premium Heavy-Duty Aluminium Slide & Fold Door System
The Sliding Folding 3.0 IMP Series is a next-generation aluminium slide and fold door system designed for expansive architectural openings, heavy-duty performance, and elegant contemporary aesthetics. Manufactured using premium 6063-grade aluminium alloy, this advanced system combines structural strength, smooth operation, and modern design to create flexible living and commercial spaces.
With support for door heights up to 5000 mm, panel weights up to 200 kg per sash, and glass thickness up to 38 mm, the Sliding Folding 3.0 IMP Series is the ideal solution for luxury residences, hotels, commercial buildings, and premium architectural projects.
Create Wide, Open Living Spaces
The Sliding Folding 3.0 IMP Series is engineered to maximize opening widths by allowing multiple panels to slide and fold neatly to one or both sides. This creates seamless transitions between indoor and outdoor environments while maximizing natural light, ventilation, and panoramic views.
Designed with precision-engineered hardware and robust aluminium profiles, the system ensures effortless operation, long-term durability, and exceptional performance even in demanding environments.
Key Features
Product Features
Heavy-Duty Folding System
Designed to accommodate large folding door panels while maintaining smooth, stable, and reliable operation.
Premium Aluminium Construction
Manufactured from 6063-grade aluminium alloy, providing superior strength, corrosion resistance, and long-lasting durability.
Large Glass Compatibility
Supports glass up to 38 mm, making it suitable for laminated, insulated, acoustic, and toughened glass systems.
Tall Door Capability
Designed for openings up to 5000 mm in height, making it ideal for luxury homes and premium commercial developments.
Flexible Opening Configuration
Panels can slide and fold neatly to maximize usable opening space and create a seamless connection between indoor and outdoor areas.
Enhanced Security
Compatible with both single-point and multi-point locking systems for secure operation and improved safety.
Technical Specifications
|
Specification |
Details |
|
Profile Alloy |
6063 Aluminium |
|
Maximum Door Height |
5000 mm |
|
Vertical Frame Size |
92 mm / 65 mm |
|
Frame Corner |
90° |
|
Sash Corner |
45° |
|
Sash Size |
84 mm / 83 mm |
|
Weight Capacity |
Up to 200 kg per Sash |
|
Glass Thickness |
Up to 38 mm |
|
Locking System |
Single / Multi-Point |
Ideal Applications
The Sliding Folding 3.0 IMP Series is ideal for:
