25mm 2.0 Sliding Series
25mm 2.0 Sliding Series
Premium Ultra Heavy-Duty Aluminium Sliding Window & Door System
The 25mm 2.0 Sliding Series is a next-generation aluminium sliding system engineered for ultra-large openings, exceptional load capacity, and premium architectural performance. Manufactured using high-strength 6063-grade aluminium alloy, this series combines sleek aesthetics with outstanding structural integrity, making it ideal for luxury residential, commercial, and institutional projects.
Designed to support up to 400 kg sash weight, accommodate glass up to 26 mm, and reach window heights of up to 3300 mm, the 25mm 2.0 Sliding Series delivers smooth operation, superior durability, and elegant modern design.
Next-Generation Sliding Solution for Large Openings
The 25mm 2.0 Sliding Series is designed to meet the demands of contemporary architecture where expansive openings, panoramic views, and heavy-duty performance are essential. Its precision-engineered profiles ensure effortless sliding, enhanced stability, and maximum durability while maintaining a refined, minimalist appearance.
Whether used in luxury homes, high-rise apartments, hotels, commercial complexes, or office buildings, this system offers long-lasting performance with premium functionality.
Key Features
Product Features
Premium Aluminium Construction
Manufactured using 6063-grade aluminium alloy to provide exceptional strength, corrosion resistance, and long-term durability.
Ultra Heavy-Duty Performance
Designed to support sliding panels weighing up to 400 kg, making it ideal for oversized windows and large sliding door systems.
Large Opening Capability
Supports window heights up to 3300 mm, allowing architects to create spacious interiors with uninterrupted views.
Large Glass Compatibility
Designed to accommodate glass up to 26 mm, including insulated, laminated, and toughened glass for improved safety and energy efficiency.
Modern Slim Design
The 23 mm visible interlock enhances the overall aesthetics while maximizing natural light and visibility.
Enhanced Security
Compatible with both single-point and multi-point locking systems, providing reliable protection and secure operation.
Technical Specifications
|
Specification |
Details |
|
Profile Alloy |
6063 Aluminium |
|
Maximum Window Height |
3300 mm |
|
Frame Corner |
45° |
|
Sash Corner |
45° / 90° |
|
Sash Size |
32 mm / 73.15 mm |
|
Visible Interlock Width |
23 mm |
|
Weight Capacity |
Up to 400 kg |
|
Glass Thickness |
Up to 26 mm |
|
Locking System |
Single / Multi-Point |
|
Mosquito Mesh Solution |
Yes |
|
2 Track Depth |
110 mm / 50 mm |
|
3 Track Depth |
161 mm / 50 mm |
Ideal Applications
The 25mm 2.0 Sliding Series is ideal for:
