EE 16 2.0 Sliding Series
EE 16 2.0 Sliding Series
Premium Ultra-Slim Aluminium Sliding Window & Door System
The EE 16 2.0 Sliding Series is a premium slim-profile aluminium sliding system designed for modern architecture that demands minimal sightlines, smooth performance, and superior structural strength. Manufactured using high-quality 6063-grade aluminium alloy, this series offers a perfect combination of elegance, durability, and functionality for luxury residential and commercial projects.
Featuring an ultra-slim 16 mm visible interlock, support for up to 250 kg sash weight, and compatibility with glass up to 24 mm, the EE 16 2.0 Sliding Series creates expansive glass openings with uninterrupted views and exceptional performance.
Experience Minimalist Design with Maximum Performance
The EE 16 2.0 Sliding Series is engineered for architects and designers who seek contemporary aesthetics without compromising strength or functionality. Its slim profile maximizes natural light while maintaining excellent structural stability, making it ideal for premium homes, offices, hotels, and commercial buildings.
Designed for effortless operation and long-term durability, the EE 16 2.0 Sliding Series offers a refined sliding experience with modern architectural appeal.
Key Features
Product Features
Premium Aluminium Construction
Manufactured from 6063-grade aluminium alloy for exceptional strength, corrosion resistance, and long-lasting durability.
Ultra-Slim Sightlines
The 16 mm visible interlock creates a sleek, minimalist appearance while maximizing glass area and natural daylight.
Heavy-Duty Performance
Supports sliding panels weighing up to 250 kg, ensuring smooth and reliable operation for large window and door systems.
Premium Glass Compatibility
Designed to accommodate glass up to 24 mm, suitable for toughened, laminated, and insulated glazing.
Advanced Security
Equipped with a multi-point locking system for enhanced security and reliable performance.
Precision Sliding Mechanism
Engineered with high-quality tracks and hardware compatibility to deliver smooth, quiet, and effortless operation.
Technical Specifications
|
Specification |
Details |
|
Profile Alloy |
6063 Aluminium |
|
Maximum Window Height |
3000 mm |
|
Frame Corner |
90° |
|
Sash Corner |
90° |
|
Sash Size |
35 mm / 60 mm |
|
Visible Interlock Width |
16 mm |
|
Weight Capacity |
Up to 250 kg |
|
Glass Thickness |
Up to 24 mm |
|
Locking System |
Multi-Point |
|
Mosquito Mesh Solution |
No |
|
2 Track Depth |
121 mm / 45 mm |
Ideal Applications
The EE 16 2.0 Sliding Series is suitable for:
